Sensor Fusion in AIoT — Why One Sensor Is Usually Not Enough

Every sensor has limitations. Accelerometers drift over time due to integration error. Temperature sensors have slow response times. Single-axis vibration sensors miss off-axis events. A GPS provides position but not orientation. Each sensor gives you a partial picture.

Sensor fusion is the practice of combining multiple sensor streams — possibly from different sensor types, possibly at different sample rates — to produce estimates better than any individual sensor could provide. A magnetometer and accelerometer fused together give you reliable orientation. Vibration data fused with temperature and acoustic signatures gives better machinery anomaly detection than vibration alone.

For AIoT applications specifically, sensor fusion often serves as the feature engineering step that gives the ML model richer input and produces more reliable inferences.

IMU fusion: the classic example

A 9-axis IMU contains a 3-axis accelerometer, 3-axis gyroscope, and 3-axis magnetometer. Individually:

The accelerometer measures specific force (gravity + acceleration). For orientation estimation, you can compute roll and pitch from the gravity vector — but only when the device is stationary. Under dynamic motion, the accelerometer signal is corrupted by linear acceleration.

The gyroscope measures angular velocity. Integrate it over time and you get rotation. But gyroscopes drift — small errors accumulate and the estimated orientation diverges from reality over time.

The magnetometer measures magnetic field, which points (approximately) north. This gives you heading (yaw). But magnetometers are extremely sensitive to nearby metal and electromagnetic interference.

Fused together via a complementary filter or Kalman filter: the gyroscope provides fast, accurate short-term rotation estimates. The accelerometer corrects the pitch/roll drift over time. The magnetometer corrects the yaw drift. The result is reliable orientation estimation that is both fast and stable.

This is what AHRS (Attitude and Heading Reference Systems) implementations do, and it's what flight controllers for drones use.

Environmental sensor fusion

For indoor environmental monitoring, CO2 concentration, temperature, humidity, and VOC (volatile organic compounds) are often all relevant. They're correlated — temperature affects humidity sensor readings, humidity affects CO2 readings — and the combination tells you more than any single reading.

An ML model trained on all four streams simultaneously can detect patterns that wouldn't be visible from any single sensor: specific combinations of temperature, humidity, and CO2 that correspond to overcrowded rooms, heating system malfunctions, or mould growth conditions. Each of these has a distinct multivariate signature.

For a maker project: combining a BME680 (temperature, humidity, pressure, VOC) with a CO2 sensor (MH-Z19 or SCD40) gives you a rich environmental feature vector that makes for interesting anomaly detection and classification applications.

Practical considerations

Time alignment: sensors sampled at different rates need to be aligned in time before fusion. A 100Hz IMU and a 1Hz temperature sensor can't be fused sample-by-sample. Decisions about interpolation, downsampling, or using the slower sensor as a context feature rather than a real-time input depend on the application.

Calibration: sensor fusion magnifies calibration errors. An uncalibrated magnetometer produces worse orientation estimates when fused than when used alone (where you might just ignore the bad readings). All sensors in a fused system should be calibrated.

Compute cost: Kalman filters and more sophisticated fusion algorithms have real compute requirements. On a microcontroller, a full EKF (Extended Kalman Filter) for 9-axis fusion may consume significant CPU time. Complementary filters (much simpler) often give 90% of the performance at 10% of the compute cost. Use the simpler algorithm unless you've confirmed you need more.
