ESP32 Wi-Fi Keeps Dropping. Here's the Fix That Actually Works in Production.

Your ESP32 project works perfectly at your desk, two metres from the router. You install it in the actual deployment location — a meter box, a utility room, an outdoor enclosure — and within 48 hours it's dropped the Wi-Fi connection and stopped responding. Power cycle brings it back. For a few hours.

This is one of the most common real-world deployment failures in DIY IoT work. It almost always comes down to the same three causes, and all of them are fixable in firmware.

Cause 1: No reconnect logic

The most common cause of 'dropped and never reconnected' is simply that the firmware doesn't try to reconnect. Arduino-style sketches often have Wi-Fi connection in setup() and never check connection status in loop().

The fix is explicit: check WiFi.status() regularly, and if it returns anything other than WL_CONNECTED, run the connection sequence again.

Basic version:

• In loop(), check WiFi.status() every 30 seconds.
• If not WL_CONNECTED, call WiFi.disconnect() first, then WiFi.begin().
• Wait up to 20 seconds for reconnection before giving up for this cycle.
• If still not connected after 3 attempts, restart the WiFi radio with WiFi.mode(WIFI_OFF) then WiFi.mode(WIFI_STA).

Cause 2: DHCP lease expiry

Most home routers assign IP addresses via DHCP with a lease time of 24 hours (some are set to 1 hour). When the lease expires, the router expects the device to re-request its IP. If your ESP32's TCP stack doesn't handle this correctly — and in some older ESP-IDF versions, it doesn't — the device keeps trying to use the expired IP and all network operations silently fail.

Fix 1 (easiest): assign your ESP32 a static IP via the router's DHCP reservation table. The device keeps its IP indefinitely and DHCP lease expiry is irrelevant.

Fix 2 (firmware): use WiFi.config() with a static IP in your sketch. Hardcodes the IP but eliminates DHCP entirely.

Cause 3: Weak signal causes partial disconnection

A -75dBm RSSI signal (which is barely adequate) tends to result in TCP connections that partially fail rather than cleanly fail. The device thinks it's connected (WiFi.status() returns WL_CONNECTED) but data isn't actually getting through. This is the most annoying failure mode because the reconnect logic doesn't trigger — the device thinks it's fine.

Detection: use a periodic ping or HTTP request to a known endpoint. If it fails, treat that as a connection failure and reconnect, even if WiFi.status() says connected.

"Status said WL_CONNECTED but no packets were getting through. Took me two weeks to figure out the signal was weak enough that the association stayed up but TCP was failing. Added a ping check and it's been solid for six months." — IoT developer, Bangalore

The watchdog pattern

For production deployments that can't have someone power-cycling them, use two layers of recovery:

• Software watchdog: if no successful network operation in 10 minutes, restart the WiFi radio.
• Hardware watchdog: ESP32 has a built-in watchdog timer. If loop() stops executing (hangs), it triggers a full restart. Enable with esp_task_wdt_init() and esp_task_wdt_add().
• Time-based restart: for less critical deployments, a daily deep sleep and wake cycle at 3 AM often clears accumulated state issues without affecting perceived uptime.

Power supply matters more than you think

A significant fraction of Wi-Fi drop issues that appear to be firmware problems are actually power problems. The ESP32's Wi-Fi transmitter draws up to 350mA in bursts. A USB cable with significant resistance, or a phone charger that can't sustain current, causes the supply voltage to dip during transmit, which causes the radio to malfunction or the chip to reset.

Quick test: put a 100µF capacitor directly across the 3.3V and GND pins on the ESP32 dev board. If the Wi-Fi stability improves, your power supply was the problem.
